Highly dynamic temperature control systems PRESTO™, water-cooled

Highly dynamic temperature control systems suitable for high-precision, external temperature control tasks, such as reactor temperature control, material tests, or temperature simulation.

Space-optimised, compact design
Short heating and cooling times
Large working temperature ranges without changing heat transfer media
Minimized floor space due to side panels without ventilation slits
5.7" TFT touch screen
SD card slot
Interfaces for USB, Ethernet, RS232, Modbus
Connections for alarm output, Pt100 external sensor, and standby-input
ICC cascade temperature control
Electronic level indicator
Integrated programmer for 8 x 60 steps
Class III (FL) acc. to DIN 12876-1

With water-cooled refrigerating machine
W 41, W 93, and W 93x with natural refrigerants


Highly dynamic temperature control systems PRESTO™, water-cooled

Item added to basket.

Highly dynamic temperature control systems PRESTO™, water-cooled

continue shopping go to basket

Customers also bought:

Type	Temperature	Temperature stability °C	Max. flow rate l/min	Max. delivery pressure bar	Refrigerant	Cooling capacity at 20 °C kW	Heating capacity kW	Ext. dim. (WxDxH)	Power supply	Weight kg	Plug type	IP code	PK	Cat. No.
W 40	-40 ... 250 °C	±0,01 ... ±0,05	40	1.7		1,2	2.7	330 x 590 x 670 mm	230 V, 50/60 Hz	78		IP 21	1	9857917
W 41	-45 ... 250 °C	±0,01 ... ±0,05	50	1.6	R1270	1,47	2.7	330 x 750 x 670 mm	230 V, 50 Hz	83		IP 20	1	4686944
W 50	-50 ... 250 °C	±0,05 ... ±0,1	80	3	R452A	7,5	6	530 x 665 x 1,260 mm	400 V·3/N/PE, 50 Hz	210	CEE	IP 20	1	4658069
W 50t	-50 ... 250 °C	±0,05 ... ±0,1	80	3	R452A	7,5	12	530 x 665 x 1,260 mm	400 V·3/N/PE, 50 Hz	210	CEE	IP 20	1	4658070
W 80	-80 ... 250 °C	±0,01 ... ±0,05	40	1.7		1,2	1.8	430 x 650 x 1,260 mm	230 V, 50 Hz	159	EU	IP 20	1	9857919
W 80t	-80 ... 250 °C	±0,01 ... ±0,05	40	1.7		1,2	3.4	430 x 650 x 1,260 mm	400 V·3/N/PE, 50 Hz	164	CEE	IP 20	1	9857921

Type W 40

Temperature -40 ... 250 °C

Temperature stability ±0,01 ... ±0,05°C

Max. flow rate 40l/min

Max. delivery pressure 1.7bar

Refrigerant

Cooling capacity at 20 °C 1,2kW

Heating capacity 2.7kW

Ext. dim. 330 x 590 x 670 mm(WxDxH)

Power supply 230 V, 50/60 Hz

Weight 78kg

Plug type

IP code IP 21

Cat. No. 9.857 917

Type W 41

Temperature -45 ... 250 °C

Temperature stability ±0,01 ... ±0,05°C

Max. flow rate 50l/min

Max. delivery pressure 1.6bar

Refrigerant R1270

Cooling capacity at 20 °C 1,47kW

Heating capacity 2.7kW

Ext. dim. 330 x 750 x 670 mm(WxDxH)

Power supply 230 V, 50 Hz

Weight 83kg

Plug type

IP code IP 20

Cat. No. 4.686 944

Type W 50

Temperature -50 ... 250 °C

Temperature stability ±0,05 ... ±0,1°C

Max. flow rate 80l/min

Max. delivery pressure 3bar

Refrigerant R452A

Cooling capacity at 20 °C 7,5kW

Heating capacity 6kW

Ext. dim. 530 x 665 x 1,260 mm(WxDxH)

Power supply 400 V·3/N/PE, 50 Hz

Weight 210kg

Plug type CEE

IP code IP 20

Cat. No. 4.658 069

Type W 50t

Temperature -50 ... 250 °C

Temperature stability ±0,05 ... ±0,1°C

Max. flow rate 80l/min

Max. delivery pressure 3bar

Refrigerant R452A

Cooling capacity at 20 °C 7,5kW

Heating capacity 12kW

Ext. dim. 530 x 665 x 1,260 mm(WxDxH)

Power supply 400 V·3/N/PE, 50 Hz

Weight 210kg

Plug type CEE

IP code IP 20

Cat. No. 4.658 070

Type W 80

Temperature -80 ... 250 °C

Temperature stability ±0,01 ... ±0,05°C

Max. flow rate 40l/min

Max. delivery pressure 1.7bar

Refrigerant

Cooling capacity at 20 °C 1,2kW

Heating capacity 1.8kW

Ext. dim. 430 x 650 x 1,260 mm(WxDxH)

Power supply 230 V, 50 Hz

Weight 159kg

Plug type EU

IP code IP 20

Cat. No. 9.857 919

Type W 80t

Temperature -80 ... 250 °C

Temperature stability ±0,01 ... ±0,05°C

Max. flow rate 40l/min

Max. delivery pressure 1.7bar

Refrigerant

Cooling capacity at 20 °C 1,2kW

Heating capacity 3.4kW

Ext. dim. 430 x 650 x 1,260 mm(WxDxH)

Power supply 400 V·3/N/PE, 50 Hz

Weight 164kg

Plug type CEE

IP code IP 20

Cat. No. 9.857 921
